Specifications & Technical Data:
Max Pressure: 1,000 kPa/10 Bar/145 PSI
Working Pressure: ≤ 700 kPa/7 Bar/101 PSI
Temperature Range: 1-50 C (122 F)
Max Vacuum: 17kPa (5" Hg) Negative Pressure
Nominal Volume: 84 Litres
Opening: 2.5"
Inner Material: Polyethylene
Outer Material: Glass Reinforced Epoxy
WARNING - DO NOT EXCEED OPERATING SPECIFICATIONS!
Handling Instructions:
Vessel approved for water filtration use only.
All other applications must be approved by the manufacturer.
Do not use for Pneumatic or Hydro-pneumatic application.
The vessel must NOT be exposed to temperatures lower than -30 Celcius.
This Vessel complies with all requirements of P.E.D 97/23/EC Directive
This water pressure vessel is tested & Compliant to NSF/ANSI Standard 44 for Material and Structural Requirements Only.
WARNING - For correct operation of this appliance, it is essential to observe the manufacturer's instructions.
CAUTION - Do NOT use on microbiologically unsafe water without adequate disinfection.
Check your media specifications for contaminant reduction capabilities.
Do NOT use for Pneumatic or Hydro-Pneumatic applications.
INSTRUCTIONS - Do NOT use any liquid thread sealant on this device or supplied valves )if applicable).
A pressure-limiting device to 500 kPa is required for domestic POE use if the pressure exceeds 500 kPa.
Where possible, limit direct exposure to sunlight.
Optional Add On
Media Funnel:
The specially-designed Media Funnel helps you fill the vessel without spilling expensive media, or getting the media stuck inside the drop tube! Use this funnel to save yourself from the hassle of having to try and push the drop tube back down into the dense media (because you've accidentally dropped media inside the tube, and had to pull the tube out to empty it)!
Neoprene Tank Cover:
Constructed with UV-resistant neoprene, this tank cover ensures optimal performance even in the most demanding environments. Whether you need protection against sunlight, extreme temperatures, or other exposure, this cover has got you covered. It effectively shields your tanks from harmful UV rays, preventing degradation and extending their lifespan.
